Six claw tractor technical parameters:
1. Through the control panel, can be used as three claws tractors. Can also be used as four claws tractors.
2. Track movements by motor drive worm gear and worm reducer.
3. Caterpillar lift is equipped with electric protection, prevent wrong operation.
|
Track number: |
Six groups. |
|
Traction tube range: |
φ400~φ630mm |
|
The maximum traction: |
50000N。 |
|
Effective length of caterpillar contact |
2000mm |
|
Track width: |
90mm。 |
|
Caterpillar clamping way: |
Pneumatic clamping. |
|
Traction speed: |
0.05-3m/min。 |
|
tractor power: |
5.5KW。 |
|
Control mode: |
Frequency control of motor speed (ABB). |
|
Air pressure: |
0.5~0.7Mpa |
|
power supply voltage: |
Three-phase380V/50Hz |
|
Center height: |
1300 mm |
