Winder

  • Update:2016-09-23 10:01:10
  • Class:
  • Model:
  • Price:
  • TAG:

Instructions










Before the machine is suitable for the traction of PE, PP - R, aluminous model multiple tube, cross-linking compound pipe and sheet plastic winding packaging, such as adopting automatic winding, adjust the winding speed, winding tension: winding alternately is equipped with two sets to ensure continuity of production. Adopts pneumatic opening or collapsed, and at the same time equipped with a polished rod line line, automatic line, achieve uniform rows, winding, the machine has compact structure, high degree of automation, good appearance, easy to operate.

Parameter

Winding diameter

400mm

Winding speed

0.5-15m/min

Winding width

300mm

winding pipe specifications

φ14-φ32

Air pressure

0.6MPa

Overall dimensions

2500×1150×1450mm

weight

1000kg

PE pipe simplex winding machine and double location winding machine


Simplex winding main technical parameters:


Reel diameter(mm)

1600/1800/2000

Winding speed(m/min)

0.5-8

Pipe size(mm)

75-160

winding width(mm)

1000

Winding diameter(mm)

3000

Double location winding machine for main technical parameters:


Reel diameter(mm)

600

Winding speed(m/min)

0.5-2

Pipe size(mm)

16-63

Air pressure(Mpa)

0.6
